Valve function2/2-way, closed, monostable 3/2-way, closed, monostable 3/2 open, monostable
Valve size10 mm
Max. standard nominal flow rate10 l/min at 10 mm
pneumatic working portM3
Operating pressure-0.9 bar ... 8 bar
Approvalc UL us - Recognized (OL)
CE mark (see declaration of conformity)In accordance with EU RoHS Directive
Certificate issuing authorityUL MH19482
Nominal size0.9 mm
Exhaust-air functionWith flow control option
Sealing principleSoft
DesignPoppet valve with spring return
Type of resetMechanical spring
Type of pilotingDirect
Signal status displayLED
Suitability for vacuumyes
Nominal operating voltage AC24 V
Nominal operating voltage DC5 V
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Media temperature-5 °C ... 40 °C
Degree of protectionIP40 IP65
Ambient temperature-5 °C ... 40 °C
Electrical controlIndividual connection Multi-pin plug
Note on materialsRoHS-compliant
Type of actuationElectric
Max. number of valve positions24
Valve terminal structureFixed grid
