ProtocolDeviceNet
Electrical connection 1, functionField device side
Electrical connection 1, designAngular
Electrical connection 1, connection typeSocket
Electrical connection 1, cable outletStraight
Electrical connection 1, connector systemSub-D
Electrical connection 1, number of connections/cores9
Electrical connection 1, used connections/cores6
Electrical connection 1, type of mounting2x screw 4-40 UNC-2A
Electrical connection 1, connection pattern00995638
Electrical connection 2, functionController side
Electrical connection 2, designRound
Electrical connection 2, connection typePlugs
Electrical connection 2, cable outletStraight
Electrical connection 2, connector systemM12x1, A-coded to EN 61076-2-101
Electrical connection 2, number of connections/cores5
Electrical connection 2, used connections/cores5
Electrical connection 2, connection pattern00995383
Nominal operating voltage DC24 V
Shieldingyes
Cable length0.1 m
Cable diameter6.3 mm
Cable structure4 x 0.34 mm²
Nominal cross section conductor0.34 mm²
Degree of protectionIP67
Note on degree of protectionIn assembled state
Ambient temperature-5 °C ... 50 °C
LABS (PWIS) conformityVDMA24364 zone III
Note on materialsRoHS-compliant
Corrosion resistance class CRC0 - No corrosion stress
Material cable sheathTPE-U(PUR)
