Conforms to standardEN 61131-9
Instructions on useFor use with the USB IO-Link Master Tool software (available from the Support Portal) for Windows version 7 or higher (32/64 bit).
Input voltage5 V DC at the USB connection 24 V DC ± 6 V via external supply
Input currentMax. 2.5 A via external supply Max. 600 mA at the USB connection
Output voltage24 V DC ± 10% with USB operation 24 V DC ± 6 V with external supply (max. input voltage)
Reverse polarity protectionFor operating voltage connections
Short circuit current ratingyes
Overload protectionNot available
ApprovalRCM trademark
CE mark (see declaration of conformity)To EU EMC Directive In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-10 °C ... 75 °C
Degree of protectionIP20
Ambient temperature0 °C ... 55 °C
Product weight106 g
ProtocolIO-Link®
IO-Link, Protocol versionMaster V 1.0 Master V 1.1
IO-Link, communication modeCOM1 (4.8 kB), COM2 (38.4 kB), COM3 (230.4 kB)
IO-Link, Port classA B, with accessories
IO-Link, Number of ports1
IO-Link, Process data length OUTCan be parameterised, 0-32 bytes
IO-Link, Process data length INCan be parameterised, 0-32 bytes
IO-Link, Min. cycle time1.5 ms
IO-Link, Data storage provided2 kB/port
IO-Link, Output current80 mA with USB operation Max. input current with external supply (<2.5 A)
Power supply, functionAdditional power supply
Power supply, connection typeSocket
power supply, connection systemCoaxial
Power supply, note on connection technologyfor plugs with outside diameter of 5.5 mm/inside diameter of 2.1 mm
Power supply, number of pins/wires2
Power supply, connection pattern00995993
USB interface, connection technologyUSB 2.0 type B mini
USB interface, plug pattern00995868
USB interface, galvanic isolationyes
Electrical connection for IO-Link, connection typeSocket
Electrical connection for IO-Link, connection technologyM12x1, A-coded to EN 61076-2-101
Electrical connection for IO-Link, number of pins/wires5
Electrical connection IO-Link®, occupied pins/wires3
Electrical connection for IO-Link, connection pattern00991867
Note on materialsRoHS-compliant
Material housingAnodised wrought aluminium alloy
